Compressor wheel HO-03-0022

Compressor wheel HO-03-0022

€10,06 EUR
€10,06 EUR
Znižanje Razprodano

HO-03-0022 - Compressor wheel

Brand: TurboCentras

TurboCentras Reference: HO-03-0022

HO-03-0022 - Alternative numbers

TCP (TurboCentras part number): HO-03-0022

HO-03-0022 - Compatibility table

Compressor wheel HO-03-0022 - Compatible turbochargers
TURBO MAKER TURBO MODEL TURBO REFERENCE TURBO PART NUMBER TURBO OE NUMBER
Holset HX25 2834997 2834997, 2834998, 3786837H 504328273
Holset HX25 2835000 2835000, 2835001, 2835002, 4033944H 2857052, 504311091
Holset HX25W 2835579 2835579, 2835591 504308750
Holset HX25W 2841579 2841579, 2841582 252714510139
Holset HX25W 2841580 2841580, 2841583 252714510148
Holset HX25 2841581 2841581, 2841584 252714510149
Holset HX25 2843037 2843037, 2843038 504374907
Holset HX25W 2843145 2843145, 2843156, 3783383, 4033826, 4033826H 5801583609, 84300602
Holset HX25W 2843146 2843146 --
Holset HX25W 3538993 3538834, 3538993 --
Holset HX25W 3590067 3590067, 3590068 --
Holset HX25W 3593370 3593370, 3593371 --
Holset HX25 3593374 3593374, 3593375 4894551
Holset HX25W 3595526 3595526, 3595527 --
Holset HX25W 3595586 3595586 --
Holset HX25W 3596065 3596065, 3596066 4025332
Holset HX25 3596222 3596222, 3596223, 3596223H 252714510109
Holset HX25W 3596584 3538835, 3538835H, 3596584 3806299
Holset HX25W 3596586 3596586, 3596596, 3596596H 3806298
Holset HX25W 3598723 3598723, 3598724, 4033350, 4033350H 504010328
Holset HX25W 3598866 3598866, 3598867, 4033305, 4033305H 504053901
Holset HX25W 3599049 3597938, 3599049, 4033161, 4033161H 4895271
Holset HX25W 3599080 3598012, 3599080, 4033081, 4033081H 504047473
Holset HX25W 3599242 3599242, 3599243 504027675
Holset HX25W 3599350 3599350, 3599351, 4033163, 4033163H, 4042194 2852068, 504061374
Holset HX25W 3599355 3599355, 3599356 4089714
Holset HX25 3599877 3599877, 3599878, 4033945H 504053177
Holset HX25 3599879 3599879, 3599880, 4033587H, 4042193 2852507, 504043175
Holset HX25W 3769602 3769602, 3769603 5801426276
Holset HX25W 3770780 3770780, 3770789, 4033828, 4033828H, 5452888 5802191586, 84554826
Holset HX25 3776600 3776600, 3776601 5801508209
Holset HX25 3777945 3777945, 3777946 --
Holset HX25 3777947 3777947, 3777948, 3778405 3778405
Holset HX25 3777950 3777950, 3777951 --
Holset HX25 3781496 3781495, 3781496 252714510163
Holset HX25 3783851 3783384, 3783851 GE405705
Holset HX25 3785749 3785742, 3785749, 3787034H ID500681
Holset HX25 4031458 4031458 --
Holset HX25 4031555 4031555, 4031556 P05292000031
Holset HX25 4031588 4031585, 4031588 006010823H91
Holset HX25 4031652 4031652, 4031653 T60011301
Holset HX25 4031672 4031672, 4031673 DE006101
Holset HX25 4031751 4031751, 4031752 DE006167
Holset HX25W 4035306 4035306, 4035307 504061373
Holset HX25W 4035393 4033353, 4033353H, 4035393, 4035394, 4042195 2852275, 504057286
Holset HX25 4035720 4035720, 4035721, 4035721H --
Holset HX25 4035722 4035722, 4035726, 4035726H --
Holset HX25W 4036087 4033093, 4033093H, 4036087, 4036088 504078256
Holset HX25 4036817 4036817, 4036818 252714510116
Holset HX25 4036822 3787080H, 4036822, 4036823 252714510117
Holset HX25 4037187 4033095H, 4037187, 4037188 504085543
Holset HX25W 4037195 4033387, 4033387H, 4037195, 4037196 504085513
Holset HX25W 4038113 4033248, 4033248H, 4038113, 4038114 504081663
Holset HX25W 4038790 4033351H, 4038790, 4038791 4089714
Holset HX25W 4038792 4033653, 4033653H, 4038792, 4038793 4025332
Holset HX25W 4038794 4033652, 4038794, 4038795, 4038795H --
Holset HX25W 4038796 4038796, 4038797, 4038797H 4955203
Holset HX25 4038833 4038833, 4038834 252714510121
Holset HX25W 4038883 4038883, 4038884 ID204343
Holset HX25 4039903 4039903, 4039904 --
Holset HX25W 4041367 4033103, 4033103H, 4041367, 4041368 504127334
Holset HX25 4041547 3786746, 3786746H, 4041547, 4041549 252714510124
Holset HX25W 4041662 4041662, 4041663, 4041664 2854359, 504122698
Holset HX25 4041670 4033184H, 4041670, 4041671, 4041672 2854361, 504122704
Holset HX25 4042226 4033349H, 4042226, 4042227 504117096
Holset HX25 4042568 4031552, 4042568, 4042569, 4043176 P0203008
Holset HX25W 4044739 4044739, 4044740 --
Holset HX25 4045324 4033252H, 4045324, 4045329 504226542
Holset HX25 4045325 4033382H, 4045325, 4045330 504226545
Holset HX25 4045326 4045326, 4045331 504221667
Holset HX25W 4045352 4045352 --
Holset HX25 4045361 4033415H, 4045361, 4045362 504225294
Holset HX25 4045365 3786643, 3786643H, 4045365, 4045366, 4047364 2856205, 3786643, 504226541
Holset HX25 4045367 4033253H, 4045367, 4045368 504226543
Holset HX25 4045798 4045798, 4045799 504238957
Holset HX25W 4046530 4033100, 4033100H, 4046530, 4046531 504202795
Holset HX25W 4047259 3786662, 3786662H, 4047259, 4047260 504274412
Holset HX25W 4047514 4047514, 4047515 006004431F1
Holset HX25 4047572 4047572, 4047573 504226538
Holset HX25 4047940 4033623H, 4047940, 4047941 504257855
Holset HX25 4048364 3787145H, 4048364, 4048365 504292715
Holset HX25 4048377 3786540H, 4048377, 4048378 504295818
Holset HX25 4049942 4033624H, 4049942, 4049946 504271999
Holset HX25 4049990 2834004, 4049990 504256434

HO-03-0022 - Part Properties

Blades (Compressor wheel blades count): 6/6

Rotation (Compressor wheel rotation direction): Standard

Type (Compressor wheel production method type): Cast

Back (Compressor wheel back design): Super

A (Size A): 56.00

A1 (Size A1): 56.00

B (Size B): 38.80

C (Size C): 4.45

C1 (Size C1): 1.90

D (Size D): 26.20

E (Size E): 5.00

HO-03-0022
HO-03-0022
2834997, 2834998, 3786837H, 504328273, 2835000, 2835001, 2835002, 2857052, 4033944H, 504311091, 2835579, 2835591, 504308750, 252714510139, 2841579, 2841582, 252714510148, 2841580, 2841583, 252714510149, 2841581, 2841584, 2843037, 2843038, 504374907, 2843145, 2843156, 3783383, 4033826, 4033826H, 5801583609, 84300602, 2843146, 3538834, 3538993, 3590067, 3590068, 3593370, 3593371, 3593374, 3593375, 4894551, 3595526, 3595527, 3595586, 3596065, 3596066, 4025332, 252714510109, 3596222, 3596223, 3596223H, 3538835, 3538835H, 3596584, 3806299, 3596586, 3596596, 3596596H, 3806298, 3598723, 3598724, 4033350, 4033350H, 504010328, 3598866, 3598867, 4033305, 4033305H, 504053901, 3597938, 3599049, 4033161, 4033161H, 4895271, 3598012, 3599080, 4033081, 4033081H, 504047473, 3599242, 3599243, 504027675, 2852068, 3599350, 3599351, 4033163, 4033163H, 4042194, 504061374, 3599355, 3599356, 4089714, 3599877, 3599878, 4033945H, 504053177, 2852507, 3599879, 3599880, 4033587H, 4042193, 504043175, 3769602, 3769603, 5801426276, 3770780, 3770789, 4033828, 4033828H, 5452888, 5802191586, 84554826, 3776600, 3776601, 5801508209, 3777945, 3777946, 3777947, 3777948, 3778405, 3778405, 3777950, 3777951, 252714510163, 3781495, 3781496, 3783384, 3783851, GE405705, 3785742, 3785749, 3787034H, ID500681, 4031458, 4031555, 4031556, P05292000031, 006010823H91, 4031585, 4031588, 4031652, 4031653, T60011301, 4031672, 4031673, DE006101, 4031751, 4031752, DE006167, 4035306, 4035307, 504061373, 2852275, 4033353, 4033353H, 4035393, 4035394, 4042195, 504057286, 4035720, 4035721, 4035721H, 4035722, 4035726, 4035726H, 4033093, 4033093H, 4036087, 4036088, 504078256, 252714510116, 4036817, 4036818, 252714510117, 3787080H, 4036822, 4036823, 4033095H, 4037187, 4037188, 504085543, 4033387, 4033387H, 4037195, 4037196, 504085513, 4033248, 4033248H, 4038113, 4038114, 504081663, 4033351H, 4038790, 4038791, 4089714, 4025332, 4033653, 4033653H, 4038792, 4038793, 4033652, 4038794, 4038795, 4038795H, 4038796, 4038797, 4038797H, 4955203, 252714510121, 4038833, 4038834, 4038883, 4038884, ID204343, 4039903, 4039904, 4033103, 4033103H, 4041367, 4041368, 504127334, 252714510124, 3786746, 3786746H, 4041547, 4041549, 2854359, 4041662, 4041663, 4041664, 504122698, 2854361, 4033184H, 4041670, 4041671, 4041672, 504122704, 4033349H, 4042226, 4042227, 504117096, 4031552, 4042568, 4042569, 4043176, P0203008, 4044739, 4044740, 4033252H, 4045324, 4045329, 504226542, 4033382H, 4045325, 4045330, 504226545, 4045326, 4045331, 504221667, 4045352, 4033415H, 4045361, 4045362, 504225294, 2856205, 3786643, 3786643, 3786643H, 4045365, 4045366, 4047364, 504226541, 4033253H, 4045367, 4045368, 504226543, 4045798, 4045799, 504238957, 4033100, 4033100H, 4046530, 4046531, 504202795, 3786662, 3786662H, 4047259, 4047260, 504274412, 006004431F1, 4047514, 4047515, 4047572, 4047573, 504226538, 4033623H, 4047940, 4047941, 504257855, 3787145H, 4048364, 4048365, 504292715, 3786540H, 4048377, 4048378, 504295818, 4033624H, 4049942, 4049946, 504271999, 2834004, 4049990, 504256434

Data updated: 2025-03-10 12:20:27
