Turbo 776470-0003
Turbo 776470-0003
Podatka o razpoložljivosti osebnega prevzema ni mogoče naložiti
776470-0003 (059145722R, 95512302500) - Turbocharger GTB2260VK
Brand: Garrett
Model: GT22 - GTB2260VK
Garrett Reference: 776470-0003
OEM Numbers: 059145722R, 95512302500
776470-0003 - Alternative numbers
GHT (Garrett turbo number): 776470-0003
GHT (Garrett turbo number): 776470-5003S
GHT (Garrett turbo number): 776470-5003W
GHT (Garrett turbo number): 776470-9003W
776470-0003 - Technologies and actuation
Actuation type: Electric (Electric actuator)
Turbocharger technology: VGT (Variable Geometry (VFT, VG, VGS, VGT, VNT, VTG) Turbocharger)
776470-0003 - Turbo replacements
Replacement for: Garrett GTB2260VK 769909-0009, 059145722M, 6C1Q6K682EK
Replacement for: Garrett GTB2260VK 769909-0010, 059145722M, 769909-5010S
Replacement for: Garrett GTB2260VK 776470-0001, 059145722R, 776470-5001S
776470-0003 - Turbo interchangeability
Interchangeable with: Garrett GTB2260VK 769909-0009, 059145722M, 6C1Q6K682EK
Interchangeable with: Garrett GTB2260VK 769909-0010, 059145722M, 769909-5010S
Interchangeable with: Garrett GTB2260VK 776470-0001, 059145722R, 776470-5001S
Interchangeable with: Garrett GTB2260VK 776470-0003-R, 059145722R, 776470-0003, 776470-9003S, 776470-9003W, 95512302500
| PART BRAND | PART NAME | PART REFERENCE | QTY | PART OE NUMBER | GARRETT PART NUMBER |
|---|---|---|---|---|---|
| Hella | Actuator | 6NW009550-041 | 1 | -- | 767649-0020 |
| TurboCentras | Bolt | BO-98-0004 | 6 | -- | -- |
| TurboCentras | Bolt | BO-98-0005 | 6 | -- | -- |
| TurboCentras | Shaft with rotor | EAS-1 | 1 | -- | -- |
| TurboCentras | Cartridge | GA-00-0197 | 1 | -- | -- |
| TurboCentras | Bearing housing | GA-01-0138 | 1 | -- | -- |
| TurboCentras | Shaft and wheel | GA-02-0110 | 1 | -- | -- |
| TurboCentras | Compressor wheel | GA-03-0087 | 1 | 784369-0002, 787571-0002 | -- |
| TurboCentras | Repair kit | GA-04-0016 | 1 | -- | -- |
| TurboCentras | Heat shield | GA-05-0018 | 1 | -- | -- |
| TurboCentras | Nozzle ring assy. | GA-06-0040 | 1 | -- | -- |
| TurboCentras | VNT nozzle cage | GA-07-0008 | 1 | -- | -- |
| TurboCentras | Back plate | GA-08-0045 | 1 | 730078-0001 | -- |
| TurboCentras | Turbine housing | GA-09-0016 | 1 | -- | -- |
| TurboCentras | Shaft nut | GA-21-0005 | 1 | -- | -- |
| TurboCentras | Actuator clip | GR.5 | 1 | -- | -- |
| TurboCentras | Thrust bearing | GT15-120 | 1 | -- | -- |
| TurboCentras | Thrust flinger | GT15-130 | 1 | -- | -- |
| TurboCentras | Thrust Collar | GT15-135 | 1 | -- | -- |
| TurboCentras | Retaining ring | GT15-143 | 1 | -- | -- |
| TurboCentras | Piston ring | GT15-160 | 2 | -- | -- |
| TurboCentras | Piston ring | GT15-170 | 1 | -- | -- |
| TurboCentras | Anti-rotation pin | GT15-330 | 1 | -- | -- |
| EE Turbo | Cartridge | GT22-026 | 1 | -- | -- |
| TurboCentras | Screw | SC-96-0007 | 4 | -- | -- |
| TurboCentras | Gasket oil outlet | T-1 | 1 | -- | -- |
| TurboCentras | Washer | WA-95-0001 | 4 | -- | -- |
059145722R, 776470-0003, 776470-5003S, 776470-5003W, 776470-9003W, 95512302500
Data updated: 2025-09-02 15:51:22
