Garrett
Turbo 766340-0001
Turbo 766340-0001
Podatka o razpoložljivosti osebnega prevzema ni mogoče naložiti
766340-0001 (55205483) - Turbocharger GT1749MV
Brand: Garrett
Model: GT17 - GT1749MV
Garrett Reference: 766340-0001
OEM Numbers: 55205483
766340-0001 - Alternative numbers
GHT (Garrett turbo number): 766340-0001
GHT (Garrett turbo number): 766340-5001S
766340-0001 - Technologies and actuation
Actuation type: Vacuum (Vacuum actuator)
Turbocharger technology: VGT (Variable Geometry (VFT, VG, VGS, VGT, VNT, VTG) Turbocharger)
766340-0001 - Turbo replacements
Replaced by: Garrett GT1749MV 766340-0002, 55190872, 55196766, 55196859, 55205356, 55205483, 766340-5002S, 766340-9002S
766340-0001 - Turbo interchangeability
Interchangeable with: Garrett GT1749MV 740067-0002, 55188659, 55190872, 55193106, 55195788, 55196766, 55196859, 55205356, 55205483, 55211063, 55217692, 740067-5002S, 93184791
Interchangeable with: Garrett GT1749MV 755046-0001, 55196859
Interchangeable with: Garrett GT1749MV 755046-0002, 55196766
Interchangeable with: Garrett GT1749MV 755046-0003, 55205356
Interchangeable with: Garrett GT1749MV 766340-0001-R, 55205483, 766340-0001, 766340-5001S
Interchangeable with: Garrett GT1749MV 766340-0002, 55190872, 55196766, 55196859, 55205356, 55205483, 766340-5002S, 766340-9002S
Interchangeable with: Garrett GT1749MV 766340-5001S, 55205483, 766340-0001
| PART BRAND | PART NAME | PART REFERENCE | QTY | PART OE NUMBER | GARRETT PART NUMBER |
|---|---|---|---|---|---|
| TurboCentras | Bolt | BO-98-0004 | 6 | -- | -- |
| TurboCentras | Bolt | BO-98-0005 | 6 | -- | -- |
| TurboCentras | Cartridge | GA-00-0113 | 1 | -- | -- |
| TurboCentras | Bearing housing | GA-01-0100 | 1 | -- | -- |
| TurboCentras | Shaft and wheel | GA-02-0006 | 1 | 729099-0001 | -- |
| TurboCentras | Compressor wheel | GA-03-0056 | 1 | 717694-0016 | -- |
| TurboCentras | Repair kit | GA-04-0015 | 1 | -- | -- |
| TurboCentras | Heat shield | GA-05-0013 | 1 | -- | -- |
| TurboCentras | Nozzle ring assy. | GA-06-0026 | 1 | -- | -- |
| TurboCentras | Back plate | GA-08-0034 | 1 | -- | -- |
| TurboCentras | Turbine housing | GA-09-0011 | 1 | -- | -- |
| TurboCentras | Actuator | GA-10-0045 | 1 | -- | -- |
| TurboCentras | Shaft nut | GA-21-0005 | 1 | -- | -- |
| TurboCentras | Actuator clip | GR.5 | 1 | -- | -- |
| TurboCentras | Thrust bearing | GT15-120 | 1 | -- | -- |
| TurboCentras | Thrust flinger | GT15-130 | 1 | -- | -- |
| TurboCentras | Thrust Collar | GT15-135 | 1 | -- | -- |
| TurboCentras | Retaining ring | GT15-143 | 1 | -- | -- |
| TurboCentras | Piston ring | GT15-160 | 1 | -- | -- |
| TurboCentras | Piston ring | GT15-170 | 1 | -- | -- |
| TurboCentras | Anti-rotation pin | GT15-330 | 1 | -- | -- |
| EE Turbo | Cartridge | GT17-026 | 1 | -- | -- |
| TurboCentras | VNT outer gasket | GT17-149-1 | 1 | -- | -- |
| TurboCentras | Screw | SC-96-0007 | 4 | -- | -- |
| TurboCentras | Gasket oil outlet | T-1 | 1 | -- | -- |
| TurboCentras | Gasket kit | TC1024 | 1 | -- | -- |
| TurboCentras | Gasket kit | TC1024F | 1 | -- | -- |
| TurboCentras | Washer | WA-95-0001 | 4 | -- | -- |
55205483, 766340-0001, 766340-5001S
Data updated: 2024-10-22 09:41:48
