Garrett
Turbo 773087-0002 (R)
Turbo 773087-0002 (R)
Redna cena
€280,00 EUR
Redna cena
Znižana cena
€280,00 EUR
Cena na enoto
/
na
Podatka o razpoložljivosti osebnega prevzema ni mogoče naložiti
773087-0002 (8200740282E) - Turbocharger
Brand: Garrett
Garrett Reference: 773087-0002
OEM Numbers: 8200740282E
773087-0002 - Alternative numbers
GHO (Garrett original part number): 773087-0002
GHA (Garrett aftermarket part number): 773087-5002S
GHR (Garrett remanufactured part number): 773087-9003S
773087-0002 - Technologies and actuation
Actuation type: Vacuum (Vacuum actuation)
Turbocharger technology: VNT (Variable Nozzle Turbine)
773087-0002 - Turbo replacements
Replaced by: Garrett GTA1549V 773087-0003
Replacement for: Garrett GTA1549V 773087-0001
773087-0002 - Turbo interchangeability
Interchangeable with: Garrett GTA1549V 773087-0001
Interchangeable with: Garrett GTA1549V 773087-0003
| Turbo 773087-0002 - Compatible parts | |||||
|---|---|---|---|---|---|
| PART BRAND | PART NAME | PART REFERENCE | QTY | PART OE NUMBER | GARRETT PART NUMBER |
| TurboCentras | Actuator clip | GR.5 | 1 | -- | -- |
| TurboCentras | Nozzle ring assy. | GT15-06-01 | 1 | -- | -- |
| TurboCentras | Journal bearing | GT15-101 | 1 | -- | -- |
| TurboCentras | Thrust bearing | GT15-120 | 1 | -- | -- |
| TurboCentras | Thrust flinger | GT15-130 | 1 | -- | -- |
| TurboCentras | Thrust Collar | GT15-135 | 1 | -- | -- |
| TurboCentras | Retaining ring (B) | GT15-143 | 1 | -- | -- |
| TurboCentras | Piston ring (turbine) | GT15-160 | 1 | -- | -- |
| TurboCentras | Piston ring (compr.) | GT15-170 | 1 | -- | -- |
| TurboCentras | Shaft nut | GT15-180 | 1 | -- | -- |
| TurboCentras | O-ring (compr.) | GT15-201 | 1 | -- | -- |
| TurboCentras | O-ring (compr.) | GT15-202 | 1 | -- | -- |
| TurboCentras | O-ring (compr.) | GT15-203 | 1 | -- | -- |
| TurboCentras | O-ring (compr.) | GT15-204 | 1 | -- | -- |
| TurboCentras | O-ring (compr.) | GT15-205 | 1 | -- | -- |
| TurboCentras | O-ring (backplate) | GT15-206 | 1 | -- | -- |
| TurboCentras | Cartridge | GT15-254 | 1 | -- | -- |
| TurboCentras | Bearing housing | GT15-313 | 1 | -- | -- |
| TurboCentras | Heat shield | GT15-324 | 1 | -- | 433112-0001 |
| TurboCentras | Anti-rotation pin | GT15-330 | 1 | -- | -- |
| TurboCentras | Shaft and wheel | GT15-48 | 1 | -- | -- |
| TurboCentras | Repair kit | GT15-50 | 1 | -- | -- |
| TurboCentras | Compressor wheel | GT17-03 | 1 | -- | -- |
| TurboCentras | Back plate | GT17-63 | 1 | -- | -- |
| TurboCentras | Bolt | M5X18 | 4 | -- | -- |
| TurboCentras | Bolt | M5X8 | 6 | -- | -- |
| TurboCentras | Bolt | M6 | 4 | -- | -- |
| TurboCentras | Bolt | M6X10 | 6 | -- | -- |
| TurboCentras | Gasket oil outlet | T-1 | 1 | -- | -- |
| TurboCentras | Gasket oil outlet | T-2 | 1 | -- | -- |
| TurboCentras | Gasket oil outlet | T-2-2 | 1 | -- | -- |
773087-0002, 773087-5002S, 773087-9003S, 8200740282E
Data updated: 2021-09-21 10:05:50
