Garrett
Turbo 752610-0015 (R)
Turbo 752610-0015 (R)
Podatka o razpoložljivosti osebnega prevzema ni mogoče naložiti
752610-0015 (6C1Q6K682EK, LR006869) - Turbocharger
Brand: Garrett
Garrett Reference: 752610-0015
OEM Numbers: 6C1Q6K682EK, LR006869
752610-0015 - Alternative numbers
GHO (Garrett original part number): 752610-0015
GHA (Garrett aftermarket part number): 752610-5015S
752610-0015 - Technologies and actuation
Actuation type: Electric (Electric actuation)
Turbocharger technology: VNT (Variable Nozzle Turbine)
752610-0015 - Turbo replacements
Replaced by: Garrett GTA2052VK 752610-0025
Replaced by: Garrett GTA2052VK 752610-0026
Replaced by: Garrett GTA2052VK 752610-0029
Replaced by: Garrett GTA2052VK 752610-0032
Replaced by: Garrett GTA2052V 752610-0035
Replacement for: Garrett GTA2052VK 752610-0009
Replacement for: Garrett GTA2052VK 752610-0010
Replacement for: Garrett GTA2052VK 752610-0012
Replacement for: Garrett GTA2052VK 752610-0013
752610-0015 - Turbo interchangeability
Interchangeable with: Garrett GTA2052VK 752610-0009
Interchangeable with: Garrett GTA2052VK 752610-0010
Interchangeable with: Garrett GTA2052VK 752610-0012
Interchangeable with: Garrett GTA2052VK 752610-0013
Interchangeable with: Garrett GTA2052VK 752610-0025
Interchangeable with: Garrett GTA2052VK 752610-0026
Interchangeable with: Garrett GTA2052VK 752610-0029
Interchangeable with: Garrett GTA2052VK 752610-0032
Interchangeable with: Garrett GTA2052V 752610-0035
| Turbo 752610-0015 - Compatible parts | |||||
|---|---|---|---|---|---|
| PART BRAND | PART NAME | PART REFERENCE | QTY | PART OE NUMBER | GARRETT PART NUMBER |
| Hella | Actuator | 6NW009206-151 | 1 | -- | 752406-0048, 752406-0042 |
| TurboCentras | Actuator clip | GR.5 | 1 | -- | -- |
| TurboCentras | Journal bearing | GT15-101 | 1 | -- | -- |
| TurboCentras | Thrust bearing | GT15-120 | 1 | -- | -- |
| TurboCentras | Thrust flinger | GT15-130 | 1 | -- | -- |
| TurboCentras | Thrust Collar | GT15-135 | 1 | -- | -- |
| TurboCentras | Retaining ring (B) | GT15-143 | 1 | -- | -- |
| TurboCentras | Piston ring (turbine) | GT15-160 | 1 | -- | -- |
| TurboCentras | Piston ring (compr.) | GT15-170 | 1 | -- | -- |
| TurboCentras | Shaft nut | GT15-180 | 1 | -- | -- |
| TurboCentras | O-ring (compr.) | GT15-201 | 1 | -- | -- |
| TurboCentras | O-ring (compr.) | GT15-202 | 1 | -- | -- |
| TurboCentras | O-ring (compr.) | GT15-203 | 1 | -- | -- |
| TurboCentras | O-ring (compr.) | GT15-204 | 1 | -- | -- |
| TurboCentras | O-ring (compr.) | GT15-205 | 1 | -- | -- |
| TurboCentras | O-ring (backplate) | GT15-206 | 1 | -- | -- |
| TurboCentras | O-ring (compr.) | GT15-207 | 1 | -- | -- |
| TurboCentras | Heat shield | GT15-323 | 1 | -- | 443768-0003 |
| TurboCentras | Anti-rotation pin | GT15-330 | 1 | -- | -- |
| TurboCentras | Repair kit | GT15-50 | 1 | -- | -- |
| TurboCentras | Compressor wheel | GT20-02 | 1 | -- | 717697-0003 |
| TurboCentras | Nozzle ring assy. | GT20-06-01 | 1 | -- | -- |
| TurboCentras | VNT gasket (turbine) | GT20-149-2 | 1 | -- | -- |
| TurboCentras | Cartridge | GT20-225 | 1 | -- | -- |
| TurboCentras | Bearing housing | GT20-307 | 1 | -- | -- |
| TurboCentras | Shaft and wheel | GT20-43 | 1 | -- | -- |
| TurboCentras | Back plate | GT20-61 | 1 | -- | 730078-0003 |
| TurboCentras | Bolt | M5X18 | 4 | -- | -- |
| TurboCentras | Bolt | M5X8 | 6 | -- | -- |
| TurboCentras | Bolt | M6 | 4 | -- | -- |
| TurboCentras | Bolt | M6X10 | 6 | -- | -- |
| TurboCentras | Gasket oil outlet | T-1 | 1 | -- | -- |
6C1Q6K682EK, 752610-0015, 752610-5015S, LR006869
Data updated: 2021-10-05 16:32:31
