Garrett
Turbo 758352-0005 (R)
Turbo 758352-0005 (R)
Podatka o razpoložljivosti osebnega prevzema ni mogoče naložiti
758352-0005 (7796311E) - Turbocharger
Brand: Garrett
Garrett Reference: 758352-0005
OEM Numbers: 7796311E
758352-0005 - Alternative numbers
GHO (Garrett original part number): 758352-0005
GHA (Garrett aftermarket part number): 758352-5005S
758352-0005 - Technologies and actuation
Actuation type: REA (Rotary Electronic Actuator)
Turbocharger technology: VNT (Variable Nozzle Turbine)
758352-0005 - Turbo replacements
Replaced by: Garrett GTB2260VK 758352-0009
Replaced by: Garrett GTB2260VK 758352-0011
Replaced by: Garrett GTB2260VK 758352-0013
Replaced by: Garrett GTB2260VK 758352-0015
Replaced by: Garrett GTB2260VK 758352-0017
Replaced by: Garrett GTB2260VK 758352-0021
Replaced by: Garrett GTB2260VK 758352-0022
Replaced by: Garrett GTB2260VK 758352-0024
Replaced by: Garrett GTB2260VK 758352-0026
758352-0005 - Turbo interchangeability
Interchangeable with: Garrett GTB2260VK 758352-0009
Interchangeable with: Garrett GTB2260VK 758352-0011
Interchangeable with: Garrett GTB2260VK 758352-0013
Interchangeable with: Garrett GTB2260VK 758352-0015
Interchangeable with: Garrett GTB2260VK 758352-0017
Interchangeable with: Garrett GTB2260VK 758352-0021
Interchangeable with: Garrett GTB2260VK 758352-0022
Interchangeable with: Garrett GTB2260VK 758352-0024
Interchangeable with: Garrett GTB2260VK 758352-0026
| Turbo 758352-0005 - Compatible parts | |||||
|---|---|---|---|---|---|
| PART BRAND | PART NAME | PART REFERENCE | QTY | PART OE NUMBER | GARRETT PART NUMBER |
| Hella | Actuator | 6NW009660-071 | 1 | -- | 781751-0014, 730314-0093 |
| TurboCentras | Actuator clip | GR.5 | 1 | -- | -- |
| TurboCentras | Journal bearing | GT15-101 | 1 | -- | -- |
| TurboCentras | Thrust bearing | GT15-120 | 1 | -- | -- |
| TurboCentras | Thrust flinger | GT15-130 | 1 | -- | -- |
| TurboCentras | Thrust Collar | GT15-135 | 1 | -- | -- |
| TurboCentras | Retaining ring (B) | GT15-143 | 1 | -- | -- |
| TurboCentras | Piston ring (turbine) | GT15-160 | 2 | -- | -- |
| TurboCentras | Piston ring (compr.) | GT15-170 | 1 | -- | -- |
| TurboCentras | Shaft nut | GT15-180 | 1 | -- | -- |
| TurboCentras | O-ring (compr.) | GT15-201 | 1 | -- | -- |
| TurboCentras | O-ring (compr.) | GT15-202 | 1 | -- | -- |
| TurboCentras | O-ring (compr.) | GT15-203 | 1 | -- | -- |
| TurboCentras | O-ring (compr.) | GT15-204 | 1 | -- | -- |
| TurboCentras | O-ring (compr.) | GT15-205 | 1 | -- | -- |
| TurboCentras | O-ring (backplate) | GT15-206 | 1 | -- | -- |
| TurboCentras | Anti-rotation pin | GT15-330 | 1 | -- | -- |
| TurboCentras | Repair kit | GT15-53 | 1 | -- | -- |
| TurboCentras | Back plate | GT20-62 | 1 | -- | 730078-0001 |
| TurboCentras | Compressor wheel | GT22-07 | 1 | -- | 787571-0001 |
| TurboCentras | Cartridge | GT22-219 | 1 | -- | -- |
| TurboCentras | Heat shield | GT22-321 | 1 | -- | -- |
| TurboCentras | Shaft and wheel | GT22-38 | 1 | -- | -- |
| TurboCentras | O-ring (backplate) | K03/04-200 | 1 | -- | -- |
| TurboCentras | Bolt | M5X18 | 4 | -- | -- |
| TurboCentras | Bolt | M5X8 | 6 | -- | -- |
| TurboCentras | Bolt | M6 | 4 | -- | -- |
| TurboCentras | Bolt | M6X10 | 6 | -- | -- |
| TurboCentras | Gasket oil outlet | T-1 | 1 | -- | -- |
| TurboCentras | Gaskets kit | TC1059 | 1 | -- | -- |
| TurboCentras | Gaskets kit | TC1059F | 1 | -- | -- |
758352-0005, 758352-5005S, 7796311E
Data updated: 2022-03-08 11:49:53
