Garrett
Turbo 786137-0001-R
Turbo 786137-0001-R
Redna cena
€289,26 EUR
Redna cena
Znižana cena
€289,26 EUR
Cena na enoto
/
na
Podatka o razpoložljivosti osebnega prevzema ni mogoče naložiti
786137-0001 (55570748) - Turbocharger GTB1549V
Brand: Garrett
Model: GT15 - GTB1549V
Garrett Reference: 786137-0001
OEM Numbers: 55570748
786137-0001 - Alternative numbers
GHT (Garrett turbo number): 786137-0001
GHT (Garrett turbo number): 786137-5001S
786137-0001 - Technologies and actuation
Actuation type: Pneumatic (Pneumatic actuator)
Turbocharger technology: VGT (Variable Geometry (VFT, VG, VGS, VGT, VNT, VTG) Turbocharger)
786137-0001 - Turbo replacements
Replaced by: Garrett GTB1549V 786137-0003, 55581063, 786137-5003S, 786137-9003W
786137-0001 - Turbo interchangeability
Interchangeable with: Garrett GTB1549V 786137-0003, 55581063, 786137-5003S, 786137-9003W
| PART BRAND | PART NAME | PART REFERENCE | QTY | PART OE NUMBER | GARRETT PART NUMBER |
|---|---|---|---|---|---|
| TurboCentras | Actuator sensor | AS-6 | 1 | -- | -- |
| TurboCentras | Bolt | BO-98-0004 | 6 | -- | -- |
| TurboCentras | Bolt | BO-98-0005 | 6 | -- | -- |
| TurboCentras | Cartridge | GA-00-0077 | 1 | -- | -- |
| TurboCentras | Bearing housing | GA-01-0071 | 1 | -- | -- |
| TurboCentras | Shaft and wheel | GA-02-0004 | 1 | 760026-0001 | -- |
| TurboCentras | Compressor wheel | GA-03-0057 | 1 | 735492-0003, 784361-0003 | -- |
| TurboCentras | Repair kit | GA-04-0016 | 1 | -- | -- |
| TurboCentras | Heat shield | GA-05-0015 | 1 | -- | -- |
| TurboCentras | Nozzle ring assy. | GA-06-0027 | 1 | -- | -- |
| TurboCentras | Back plate | GA-08-0046 | 1 | -- | -- |
| TurboCentras | Actuator | GA-10-0017 | 1 | -- | -- |
| TurboCentras | Shaft nut | GA-21-0005 | 1 | -- | -- |
| TurboCentras | Actuator clip | GR.5 | 1 | -- | -- |
| EE Turbo | Cartridge | GT15-073 | 1 | -- | -- |
| TurboCentras | Thrust bearing | GT15-120 | 1 | -- | -- |
| TurboCentras | Thrust flinger | GT15-130 | 1 | -- | -- |
| TurboCentras | Thrust Collar | GT15-135 | 1 | -- | -- |
| TurboCentras | Retaining ring | GT15-143 | 1 | -- | -- |
| TurboCentras | Piston ring | GT15-160 | 2 | -- | -- |
| TurboCentras | Piston ring | GT15-170 | 1 | -- | -- |
| TurboCentras | Anti-rotation pin | GT15-330 | 1 | -- | -- |
| TurboCentras | Screw | SC-96-0007 | 4 | -- | -- |
| TurboCentras | Gasket oil outlet | T-1 | 1 | -- | -- |
| TurboCentras | Washer | WA-95-0001 | 4 | -- | -- |
55570748, 786137-0001, 786137-5001S
Data updated: 2024-10-31 08:44:42
