Garrett
Turbo 723167-0002-R
Turbo 723167-0002-R
Podatka o razpoložljivosti osebnega prevzema ni mogoče naložiti
723167-0002 (8602480, 8603296, 8653146) - Turbocharger GT2052S
Brand: Garrett
Model: GT20 - GT2052S
Garrett Reference: 723167-0002
OEM Numbers: 8602480, 8603296, 8653146
723167-0002 - Alternative numbers
GHT (Garrett turbo number): 723167-0002
GHT (Garrett turbo number): 723167-5002S
723167-0002 - Technologies and actuation
Actuation type: Pneumatic (Pneumatic actuator)
Turbocharger technology: VGT (Variable Geometry (VFT, VG, VGS, VGT, VNT, VTG) Turbocharger)
723167-0002 - Turbo replacements
Replaced by: Garrett GT2052S 723167-0003, 723167-5003S, 8602480, 8603296, 8653122
Replaced by: Garrett GT2052S 723167-0004, 723167-5004S, 8602480, 8603296, 8689592
Replaced by: Garrett GT2052V 723167-0008, 723167-5008S, 8602480, 8603296, 8689592
Replacement for: Garrett GT2052S 723167-0001, 723167-5001S, 8602480, 8603296, 8627752, 8653146
723167-0002 - Turbo interchangeability
Interchangeable with: Garrett GT2052SV 716214-0001, 716214-5001S, 8602480, 8603296, 8627752
Interchangeable with: Garrett GT2052S 723167-0001, 723167-5001S, 8602480, 8603296, 8627752, 8653146
Interchangeable with: Garrett GT2052S 723167-0003, 723167-5003S, 8602480, 8603296, 8653122
Interchangeable with: Garrett GT2052S 723167-0004, 723167-5004S, 8602480, 8603296, 8689592
Interchangeable with: Garrett GT2052V 723167-0005, 30743403
Interchangeable with: Garrett GTA2052V 723167-0007, 3847392, 723167-5007S
Interchangeable with: Garrett GT2052V 723167-0008, 723167-5008S, 8602480, 8603296, 8689592
| PART BRAND | PART NAME | PART REFERENCE | QTY | PART OE NUMBER | GARRETT PART NUMBER |
|---|---|---|---|---|---|
| TurboCentras | Bolt | BO-98-0004 | 6 | -- | -- |
| TurboCentras | Bolt | BO-98-0005 | 6 | -- | -- |
| TurboCentras | Cartridge | GA-00-0159 | 1 | -- | -- |
| TurboCentras | Bearing housing | GA-01-0116 | 1 | 722282-0022 | -- |
| TurboCentras | Shaft and wheel | GA-02-0084 | 1 | 434883-0014, 434883-0029 | -- |
| TurboCentras | Compressor wheel | GA-03-0034 | 1 | 436131-0050, 702492-0001, 702492-0004, 702492-0040 | -- |
| TurboCentras | Repair kit | GA-04-0015 | 1 | -- | -- |
| TurboCentras | Heat shield | GA-05-0012 | 1 | -- | -- |
| TurboCentras | Nozzle ring assy. | GA-06-0036 | 1 | -- | -- |
| TurboCentras | Back plate | GA-08-0007 | 1 | 701335-0003 | -- |
| TurboCentras | Shaft nut | GA-21-0005 | 1 | -- | -- |
| TurboCentras | Actuator clip | GR.5 | 1 | -- | -- |
| TurboCentras | Thrust bearing | GT15-120 | 1 | -- | -- |
| TurboCentras | Thrust flinger | GT15-130 | 1 | -- | -- |
| TurboCentras | Thrust Collar | GT15-135 | 1 | -- | -- |
| TurboCentras | Retaining ring | GT15-143 | 1 | -- | -- |
| TurboCentras | Piston ring | GT15-160 | 1 | -- | -- |
| TurboCentras | Piston ring | GT15-170 | 1 | -- | -- |
| TurboCentras | Anti-rotation pin | GT15-330 | 1 | -- | -- |
| EE Turbo | Cartridge | GT20-036 | 1 | -- | -- |
| TurboCentras | Screw | SC-96-0007 | 4 | -- | -- |
| TurboCentras | Gasket oil outlet | T-1 | 1 | -- | -- |
| TurboCentras | Gasket kit | TC1047 | 1 | -- | -- |
| TurboCentras | Washer | WA-95-0001 | 4 | -- | -- |
723167-0002, 723167-5002S, 8602480, 8603296, 8653146
Data updated: 2025-10-02 09:43:23
