Compressor wheel HO-03-0017

Compressor wheel HO-03-0017

€19,06 EUR
€19,06 EUR
Znižanje Razprodano

HO-03-0017 (3599644) - Compressor wheel

Brand: TurboCentras

TurboCentras Reference: HO-03-0017

OEM Numbers: 3599644

HO-03-0017 - Alternative numbers

TCO (TurboCentras old part number): H1C-04

TCP (TurboCentras part number): HO-03-0017

HO-03-0017 - Compatibility table

Compressor wheel HO-03-0017 - Compatible turbochargers
TURBO MAKER TURBO MODEL TURBO REFERENCE TURBO PART NUMBER TURBO OE NUMBER
Holset H1E 3525038 3525038, 3525039 --
Holset H1E 3525554 3525554, 3525555, 4033231H 17507
Holset H1E 3525688 3525688, 3525689, 3525689H 3802595
Holset WH1C 3528484 3528481, 3528482, 3528484 --
Holset H1E 3528781 3528781, 3528782, 3535458, 3535459, 3535534, 3535535 --
Holset H1E 3529680 3529346, 3529680 477452, 477580, 477581, 8112277
Holset WH1C 3529883 3529883, 3530005, 3530345, 3530346, 3530347, 3530348, 3532739, 3532740, 3532939, 3533042, 3533878, 3533879, 3533880, 3535577, 3535578 5272021
Holset H1E 3530000 3530000, 3530001, 4033099H 8008674
Holset H1E 3530474 3530474, 3530475 477668, 477669, 477670, 8112276
Holset H1E 3530669 3530669, 3530670, 4033261H 477653, 849680
Holset H1E 3530737 3530737, 3530743 --
Holset WH1C 3530996 3530996, 3530997, 3530997H --
Holset H1E 3531665 3531665 --
Holset H1C 3531667 3531667, 3531668, 3535452, 3535453 --
Holset H1E 3531721 3531721, 3531722, 3535554, 3535555 --
Holset H1C 3532031 3532031, 3532032 --
Holset H1E 3532065 3532065, 3532152, 3532152H --
Holset H1E 3532067 3532067, 3532154, 3532154H 3802427
Holset H1E 3532208 3531035, 3531035H, 3532208 3802304
Holset WH1C 3533302 3533302, 3533303, 3533304, 3533305, 3533306, 3533307, 3533308 --
Holset WH1C 3533309 3533309, 3533310, 3533311, 3533312, 3533313, 3533314, 3533315 --
Holset WH1C 3533316 3533316, 3533317 3802556
Holset WH1C 3533318 3533318, 3533319 3802557
Holset WH1C 3533320 3533320, 3533321 --
Holset H1E 3533383 3533383, 3533384 3804493
Holset H1E 3533477 3267861, 3533477, 3533478 3803795
Holset H1E 3533735 3533735, 3533736, 3533737 --
Holset WH1C 3534333 3534333, 3534474 --
Holset H1E 3534375 3534375, 3534376, 3534376H 3802590
Holset WH1C 3534452 3534452, 3534453, 3535294 --
Holset WH1C 3534927 3534927, 3534928, 3534928H 3802597
Holset WH1C 3534929 3534929, 3534930, 3534930H --
Holset WH1C 3534931 3534931, 3534932, 3534932H 3802599
Holset H1E 3535361 3535361, 3535362 127492-18510
Holset WH1C 3536109 3536109, 3536115, 3536116 --
Holset WH1C 3536212 3536212, 3536213, 3536213H 3802682
Holset WH1C 3536214 3536214, 3536215 --
Holset WH1C 3536218 3536218, 3536219, 3536219H 3802685
Holset WH1C 3536368 3536368, 3536421 5272022
Holset WH1C 3536725 3536725, 3536726 3802693
Holset H1C 3537359 3537359, 3537360 --
Holset HX35W 3537542 3537542, 3537543 3802500
Holset H1C 3537661 3537661, 3537662 --
Holset H1E 3538071 3538071, 3538072 --
Holset H1E 3538124 3538124, 3538125 3802832
Holset H1E 3538777 3538777, 3538778 3802910
Holset H1E 3538827 3538827, 3538828 3802883
Holset H1E 3538829 3538829, 3538830 --
Holset H1E 3539470 3539470, 3539471 --
Holset H1E 3580203 312555, 313066, 3580203, 4033711, 4033711H, 4033711HX, 466616-0002, 466616-0003, 466616-0005, 466616-0007, 466616-0009 1317664, 370090, 370091, 393457
Holset H1C 3580244 3580244, 3580244H, 465254-0004 14201Z5517

HO-03-0017 - Part Properties

Blades (Compressor wheel blades count): 8/8

Rotation (Compressor wheel rotation direction): Standard

Type (Compressor wheel production method type): Cast

Back (Compressor wheel back design): Super

A (Size A): 83.00

A1 (Size A1): 83.00

B (Size B): 56.00

C (Size C): 6.30

C1 (Size C1): 4.00

D (Size D): 40.00

E (Size E): 7.00

HO-03-0017
3599644, H1C-04, HO-03-0017
3525038, 3525039, 17507, 3525554, 3525555, 4033231H, 3525688, 3525689, 3525689H, 3802595, 3528481, 3528482, 3528484, 3528781, 3528782, 3535458, 3535459, 3535534, 3535535, 3529346, 3529680, 477452, 477580, 477581, 8112277, 3529883, 3530005, 3530345, 3530346, 3530347, 3530348, 3532739, 3532740, 3532939, 3533042, 3533878, 3533879, 3533880, 3535577, 3535578, 5272021, 3530000, 3530001, 4033099H, 8008674, 3530474, 3530475, 477668, 477669, 477670, 8112276, 3530669, 3530670, 4033261H, 477653, 849680, 3530737, 3530743, 3530996, 3530997, 3530997H, 3531665, 3531667, 3531668, 3535452, 3535453, 3531721, 3531722, 3535554, 3535555, 3532031, 3532032, 3532065, 3532152, 3532152H, 3532067, 3532154, 3532154H, 3802427, 3531035, 3531035H, 3532208, 3802304, 3533302, 3533303, 3533304, 3533305, 3533306, 3533307, 3533308, 3533309, 3533310, 3533311, 3533312, 3533313, 3533314, 3533315, 3533316, 3533317, 3802556, 3533318, 3533319, 3802557, 3533320, 3533321, 3533383, 3533384, 3804493, 3267861, 3533477, 3533478, 3803795, 3533735, 3533736, 3533737, 3534333, 3534474, 3534375, 3534376, 3534376H, 3802590, 3534452, 3534453, 3535294, 3534927, 3534928, 3534928H, 3802597, 3534929, 3534930, 3534930H, 3534931, 3534932, 3534932H, 3802599, 127492-18510, 3535361, 3535362, 3536109, 3536115, 3536116, 3536212, 3536213, 3536213H, 3802682, 3536214, 3536215, 3536218, 3536219, 3536219H, 3802685, 3536368, 3536421, 5272022, 3536725, 3536726, 3802693, 3537359, 3537360, 3537542, 3537543, 3802500, 3537661, 3537662, 3538071, 3538072, 3538124, 3538125, 3802832, 3538777, 3538778, 3802910, 3538827, 3538828, 3802883, 3538829, 3538830, 3539470, 3539471, 1317664, 312555, 313066, 3580203, 370090, 370091, 393457, 4033711, 4033711H, 4033711HX, 466616-0002, 466616-0003, 466616-0005, 466616-0007, 466616-0009, 14201Z5517, 3580244, 3580244H, 465254-0004
