TurboCentras
Compressor wheel GA-03-0114
Compressor wheel GA-03-0114
Redna cena
€29,86 EUR
Redna cena
Znižana cena
€29,86 EUR
Cena na enoto
na
Podatka o razpoložljivosti osebnega prevzema ni mogoče naložiti
GA-03-0114 - Compressor wheel
Brand: TurboCentras
TurboCentras Reference: GA-03-0114
GA-03-0114 - Alternative numbers
TCP (TurboCentras part number): GA-03-0114
TCO (TurboCentras old part number): GT45-01
GA-03-0114 - Part Properties
Blades (Compressor wheel blades count): 11
Rotation (Compressor wheel rotation direction): Standard
Type (Compressor wheel production method type): Cast
Back (Compressor wheel back design): Super
A (Size A): 88.50
A1 (Size A1): 91.30
B (Size B): 59.70
C (Size C): 6.06
C1 (Size C1): 20.00
D (Size D): 68.10
E (Size E): 8.25
| TURBO MAKER | TURBO MODEL | TURBO PART NUMBERS | TURBO OE NUMBERS |
|---|---|---|---|
| Garrett | GTC4088V | 789500-0002, 789500-5002S | 504387517 |
| Garrett | GTC4088V | 789500-0003, 789500-5003S | 504374051 |
| Garrett | GTC4088BKNV | 789500-0008, 789500-5008S | 5801394956 |
| Garrett | GTC4088V | 789500-0009, 789500-5009S | 5801427840 |
| Garrett | GTC4088V | 789500-0016, 789500-5016S | 5801621754 |
| Garrett | GTC4088BKNV | 789500-0017, 789500-5017S | 5801621755 |
| Garrett | GTC4088V | 789500-0018, 789500-5018S | 5801621756 |
| Garrett | GTC4088V | 789500-0020, 789500-5020S | 5801661507 |
| Garrett | GTC4088BKNV | 789500-0021, 789500-5021S | 5801677550 |
| Garrett | GTC3788BNS | 811223-0001, 811223-5001S | 5801452789 |
| Garrett | GTC3788BNS | 811223-0006, 811223-5006S | 5801621763 |
| Garrett | GTC3788BNS | 811223-0007, 811223-5007S | 5801621762 |
| Garrett | GTC3788BNS | 811223-0008, 811223-5008S | 5801621764 |
| Garrett | GTC3788BNS | 811223-0009, 811223-5009S | 5801661503 |
| Garrett | GTC3788BNS | 811223-0010, 811223-5010S | 5801661505 |
| Garrett | GTC3788BNS | 811223-0017 | -- |
| Garrett | GTC3788BNS | 811223-0020, 811223-5020S | 5802200487 |
| Garrett | GTC4094BKNV | 841805-0002, 841805-5002S | 5802507354 |
| Garrett | GTC40888BKNV | 841805-0004, 841805-5004S | 5802133357 |
| Garrett | GTC4094BKNV | 841805-0005, 841805-5005S | 5802507409 |
| Garrett | GTC4088BKNV | 841805-0006, 841805-5006S | 5802463495 |
| Garrett | GTC4088BKNV | 841805-0010 | -- |
| Garrett | GTC4088BKNV | 841805-0011, 841805-5011S | 5802507353 |
| Garrett | GTC4088V | 841805-0012, 841805-5012S | 5802507354 |
| Garrett | GTC4088BKNV | 841805-0014 | -- |
| Garrett | GTC4088V | 841805-0015, 841805-5015S | 5802507351 |
| Garrett | GTC4088BKNV | 841805-0018, 841805-5018S | 5802200812 |
| Garrett | GTC4088BKNV | 841805-0020, 841805-5020S | 5802703202 |
| Garrett | GTC3788BNS | 856254-0002, 856254-5002S | 5802353349 |
| Garrett | GTC3788BNS | 856254-0004 | -- |
| Garrett | GTC3788BNS | 856254-0005 | -- |
| Garrett | GTC3788BNS | 856254-0007, 856254-5007S | 5802507331 |
| Garrett | GTC3788BNS | 856254-0008 | -- |
| Garrett | GTC3788BNS | 895368-0002 | 5802743519 |
| Garrett | GTC3788BNS | 895368-0003 | 5802743518 |
| Garrett | GTC3788BNS | 895368-0004 | 5802743517 |
GA-03-0114 - Used in turbocharges
504387517, 789500-0002, 789500-5002S, 504374051, 789500-0003, 789500-5003S, 5801394956, 789500-0008, 789500-5008S, 5801427840, 789500-0009, 789500-5009S, 5801621754, 789500-0016, 789500-5016S, 5801621755, 789500-0017, 789500-5017S, 5801621756, 789500-0018, 789500-5018S, 5801661507, 789500-0020, 789500-5020S, 5801677550, 789500-0021, 789500-5021S, 5801452789, 811223-0001, 811223-5001S, 5801621763, 811223-0006, 811223-5006S, 5801621762, 811223-0007, 811223-5007S, 5801621764, 811223-0008, 811223-5008S, 5801661503, 811223-0009, 811223-5009S, 5801661505, 811223-0010, 811223-5010S, 811223-0017, 5802200487, 811223-0020, 811223-5020S, 5802507354, 841805-0002, 841805-5002S, 5802133357, 841805-0004, 841805-5004S, 5802507409, 841805-0005, 841805-5005S, 5802463495, 841805-0006, 841805-5006S, 841805-0010, 5802507353, 841805-0011, 841805-5011S, 841805-0012, 841805-5012S, 841805-0014, 5802507351, 841805-0015, 841805-5015S, 5802200812, 841805-0018, 841805-5018S, 5802703202, 841805-0020, 841805-5020S, 5802353349, 856254-0002, 856254-5002S, 856254-0004, 856254-0005, 5802507331, 856254-0007, 856254-5007S, 856254-0008, 5802743519, 895368-0002, 5802743518, 895368-0003, 5802743517, 895368-0004Data updated: 2025-06-27 12:01:30
