Garrett
Turbo 715924-0003 715924-5003S
Turbo 715924-0003 715924-5003S
Regular price
€270,00 EUR
Regular price
Sale price
€270,00 EUR
Unit price
/
per
Couldn't load pickup availability
715924-0003 (28200-42610, 2820042610) - Turbocharger
Brand: Garrett
Garrett Reference: 715924-0003
OEM Numbers: 28200-42610, 2820042610
715924-0003 - Alternative numbers
GHT (Garrett OEM, original turbo number): 715924-0003
GHA (Garrett IAM, aftermarket new turbo number): 715924-5003S
GHA (Garrett IAM, aftermarket new turbo number): 715924-5003W
715924-0003 - Technologies and actuation
Actuation type: Pneumatic (Pneumatic actuation)
Turbocharger technology: WG (Wastegate)
715924-0003 - Turbo replacements
Replacement for: Garrett GT1749S 715924-0001
715924-0003 - Turbo interchangeability
Interchangeable with: Garrett GT1749S 715924-0001
| Turbo 715924-0003 - Compatible parts | |||||
|---|---|---|---|---|---|
| PART BRAND | PART NAME | PART REFERENCE | QTY | PART OE NUMBER | GARRETT PART NUMBER |
| TurboCentras | Compressor wheel | GA-03-0030 | 1 | -- | 436132-0003, 436334-0003, 703925-0003, 436132-0014, 701300-0007, 703925-0011, 706164-0003 |
| TurboCentras | Actuator clip | GR.5 | 1 | -- | -- |
| TurboCentras | Journal bearing | GT15-101 | 1 | -- | -- |
| TurboCentras | Thrust bearing | GT15-120 | 1 | -- | -- |
| TurboCentras | Thrust flinger | GT15-130 | 1 | -- | -- |
| TurboCentras | Thrust Collar | GT15-135 | 1 | -- | -- |
| TurboCentras | Retaining ring (B) | GT15-143 | 1 | -- | -- |
| TurboCentras | Piston ring (turbine) | GT15-160 | 1 | -- | -- |
| TurboCentras | Piston ring (compr.) | GT15-170 | 1 | -- | -- |
| TurboCentras | Shaft nut | GT15-180 | 1 | -- | -- |
| TurboCentras | O-ring (compr.) | GT15-201 | 1 | -- | -- |
| TurboCentras | O-ring (compr.) | GT15-202 | 1 | -- | -- |
| TurboCentras | O-ring (compr.) | GT15-203 | 1 | -- | -- |
| TurboCentras | O-ring (compr.) | GT15-204 | 1 | -- | -- |
| TurboCentras | O-ring (compr.) | GT15-205 | 1 | -- | -- |
| TurboCentras | O-ring (backplate) | GT15-206 | 1 | -- | -- |
| TurboCentras | Bearing housing | GT15-302 | 1 | -- | 434578-0012 |
| TurboCentras | Anti-rotation pin | GT15-330 | 1 | -- | -- |
| TurboCentras | Repair kit | GT15-50 | 1 | -- | -- |
| TurboCentras | Back plate | GT15-75 | 1 | -- | 433294-0002 |
| TurboCentras | Cartridge | GT17-213 | 1 | -- | 433352-0031 |
| TurboCentras | Shaft and wheel | GT17-32 | 1 | -- | 434714-0021 |
| TurboCentras | Actuator | GT17-490 | 1 | -- | -- |
| TurboCentras | Bolt | M5X18 | 4 | -- | -- |
| TurboCentras | Bolt | M5X8 | 6 | -- | -- |
| TurboCentras | Bolt | M6 | 4 | -- | -- |
| TurboCentras | Bolt | M6X10 | 6 | -- | -- |
| TurboCentras | Gasket oil outlet | T-1 | 1 | -- | -- |
28200-42610, 2820042610, 715924-0003, 715924-5003S, 715924-5003W
Data updated: 2023-05-08 13:30:38
