Garrett
Turbo 786880-0012
Turbo 786880-0012
Regular price
€549,59 EUR
Regular price
Sale price
€549,59 EUR
Unit price
/
per
Couldn't load pickup availability
786880-0012 (BK2Q6K682HA) - Turbocharger GTB1749VK
Brand: Garrett
Model: GT17 - GTB1749VK
Garrett Reference: 786880-0012
OEM Numbers: BK2Q6K682HA
786880-0012 - Alternative numbers
GHT (Garrett turbo number): 786880-0012
GHT (Garrett turbo number): 786880-5012S
786880-0012 - Technologies and actuation
Actuation type: Electric (Electric actuator)
Turbocharger technology: VGT (Variable Geometry (VFT, VG, VGS, VGT, VNT, VTG) Turbocharger)
786880-0012 - Turbo replacements
Replaced by: Garrett GTB1749VK 786880-0023
786880-0012 - Turbo interchangeability
Interchangeable with: Garrett GTB1749VK 786880-0023
| PART BRAND | PART NAME | PART REFERENCE | QTY | PART OE NUMBER | GARRETT PART NUMBER |
|---|---|---|---|---|---|
| Hella | Actuator | 6NW009550-201 | 1 | -- | 767649-0059, 767649-59 |
| TurboCentras | Bolt | BO-98-0004 | 6 | -- | -- |
| TurboCentras | Bolt | BO-98-0005 | 6 | -- | -- |
| TurboCentras | Cartridge | GA-00-0128 | 1 | -- | -- |
| TurboCentras | Bearing housing | GA-01-0013 | 1 | -- | -- |
| TurboCentras | Shaft and wheel | GA-02-0079 | 1 | -- | -- |
| TurboCentras | Compressor wheel | GA-03-0057 | 1 | 735492-0003, 784361-0003 | -- |
| TurboCentras | Repair kit | GA-04-0016 | 1 | -- | -- |
| TurboCentras | Heat shield | GA-05-0015 | 1 | -- | -- |
| TurboCentras | Back plate | GA-08-0046 | 1 | -- | -- |
| TurboCentras | Turbine housing | GA-09-0022 | 1 | -- | -- |
| TurboCentras | Compressor housing | GA-11-0009 | 1 | -- | -- |
| TurboCentras | Shaft nut | GA-21-0005 | 1 | -- | -- |
| TurboCentras | Actuator clip | GR.5 | 1 | -- | -- |
| TurboCentras | Thrust bearing | GT15-120 | 1 | -- | -- |
| TurboCentras | Thrust flinger | GT15-130 | 1 | -- | -- |
| TurboCentras | Thrust Collar | GT15-135 | 1 | -- | -- |
| TurboCentras | Retaining ring | GT15-143 | 1 | -- | -- |
| TurboCentras | Piston ring | GT15-160 | 2 | -- | -- |
| TurboCentras | Piston ring | GT15-170 | 1 | -- | -- |
| TurboCentras | Anti-rotation pin | GT15-330 | 1 | -- | -- |
| EE Turbo | Cartridge | GT17-074 | 1 | -- | -- |
| TurboCentras | Screw | SC-96-0007 | 4 | -- | -- |
| TurboCentras | Gasket oil outlet | T-1 | 1 | -- | -- |
| TurboCentras | Gasket kit | TC1072 | 1 | -- | -- |
| TurboCentras | Washer | WA-95-0001 | 4 | -- | -- |
786880-0012, 786880-5012S, BK2Q6K682HA
Data updated: 2024-05-17 09:59:21
