Garrett
Turbo 787556-0017-R 787556-0017 (R)
Turbo 787556-0017-R 787556-0017 (R)
Regular price
€350,00 EUR
Regular price
Sale price
€350,00 EUR
Unit price
/
per
Couldn't load pickup availability
787556-0017-R (BK3Q-6K682-CB, BK3Q6K682CB) - Turbocharger GTB1749V
Brand: Garrett
Model: GT17 - GTB1749V
Garrett Reference: 787556-0017-R
OEM Numbers: BK3Q-6K682-CB, BK3Q6K682CB
787556-0017-R - Alternative numbers
GHT (Garrett turbo number): 787556-0017
GHT (Garrett turbo number): 787556-9017S
787556-0017-R - Technologies and actuation
Actuation type: Electric (Electric actuator)
Turbocharger technology: VGT (Variable Geometry (VFT, VG, VGS, VGT, VNT, VTG) Turbocharger)
787556-0017-R - Turbo replacements
Replaced by: Garrett GTB1749V 854800-0001
787556-0017-R - Turbo interchangeability
Interchangeable with: Garrett GTB1749V 787556-0016
Interchangeable with: Garrett GTB1749V 787556-0017
Interchangeable with: Garrett GTB1749V 787556-0022
Interchangeable with: Master Power MP215GV 805801
Interchangeable with: Garrett GTB1749V 854800-0001
| PART BRAND | PART NAME | PART REFERENCE | QTY | PART OE NUMBER | GARRETT PART NUMBER |
|---|---|---|---|---|---|
| Hella | Actuator | 6NW009550-271 | 1 | -- | 767649-0088 |
| TurboCentras | Bolt | BO-98-0004 | 6 | -- | -- |
| TurboCentras | Bolt | BO-98-0005 | 6 | -- | -- |
| TurboCentras | Cartridge | GA-00-0129 | 1 | -- | -- |
| TurboCentras | Bearing housing | GA-01-0072 | 1 | -- | -- |
| TurboCentras | Shaft and wheel | GA-02-0079 | 1 | -- | -- |
| TurboCentras | Compressor wheel | GA-03-0057 | 1 | 735492-0003, 784361-0003 | -- |
| TurboCentras | Repair kit | GA-04-0016 | 1 | -- | -- |
| TurboCentras | Heat shield | GA-05-0015 | 1 | -- | -- |
| TurboCentras | Nozzle ring assy. | GA-06-0027 | 1 | -- | -- |
| TurboCentras | Back plate | GA-08-0046 | 1 | -- | -- |
| TurboCentras | Shaft nut | GA-21-0005 | 1 | -- | -- |
| TurboCentras | Actuator clip | GR.5 | 1 | -- | -- |
| TurboCentras | Thrust bearing | GT15-120 | 1 | -- | -- |
| TurboCentras | Thrust flinger | GT15-130 | 1 | -- | -- |
| TurboCentras | Thrust Collar | GT15-135 | 1 | -- | -- |
| TurboCentras | Retaining ring | GT15-143 | 1 | -- | -- |
| TurboCentras | Piston ring | GT15-160 | 2 | -- | -- |
| TurboCentras | Piston ring | GT15-170 | 1 | -- | -- |
| TurboCentras | Anti-rotation pin | GT15-330 | 1 | -- | -- |
| EE Turbo | Cartridge | GT17-060 | 1 | -- | -- |
| TurboCentras | Screw | SC-96-0007 | 4 | -- | -- |
| TurboCentras | Gasket oil outlet | T-1 | 1 | -- | -- |
| TurboCentras | Washer | WA-95-0001 | 4 | -- | -- |
787556-0017, 787556-9017S, BK3Q-6K682-CB, BK3Q6K682CB
Data updated: 2024-05-17 10:04:44
