BorgWarner
Turbo 53039700132-R
Turbo 53039700132-R
Couldn't load pickup availability
53039700132 (03L253019A, 03L253019T) - Turbocharger BV43-1874KXB419.18KVAXC
Brand: BorgWarner
Model: BV43 - BV43-1874KXB419.18KVAXC
BorgWarner Reference: 53039700132
OEM Numbers: 03L253019A, 03L253019T
53039700132 - Alternative numbers
BWT (BorgWarner turbo number): 5303 970 0132
53039700132 - Technologies and actuation
Actuation type: APS (Pneumatic actuator with position sensor)
Turbocharger technology: VGT (Variable Geometry (VFT, VG, VGS, VGT, VNT, VTG) Turbocharger)
53039700132 - Turbo replacements
Replaced by: BorgWarner BV43-1874KXB419.18KVAXC 53039700205, 03L253056A, 5303 970 0205, 5303 988 0205, 5303 990 0205
53039700132 - Turbo interchangeability
Interchangeable with: BMTS BM 40007031, 03L253010C, 03L253016F, 03L253016J, 03L253016JV300, 03L253016JV410, 03L253019A, 03L253019J, 03L253019T, 03L253056A, 03L253056B, 401TN100508
Interchangeable with: BorgWarner BV43-1874KXB419.18KVAXC 53039700139, 03L253010C, 03L253016F, 03L253019J, 5303 970 0139, 5303 988 0139, BV43B-0139
Interchangeable with: BorgWarner BV43-1874KXB419.18KVAXC 53039700152, 03L253016J, 5303 970 0152
Interchangeable with: BorgWarner BV43-1874KXB419.18KVAXC 53039700205, 03L253056A, 5303 970 0205, 5303 988 0205, 5303 990 0205
| PART BRAND | PART NAME | PART REFERENCE | QTY | PART OE NUMBER | BORGWARNER PART NUMBER |
|---|---|---|---|---|---|
| BorgWarner | Actuator kit | 58307117014 | 1 | 03L198716A | -- |
| TurboCentras | Bolt | BO-98-0005 | 6 | -- | -- |
| TurboCentras | Bolt | BO-98-0007 | 4 | -- | -- |
| TurboCentras | Cartridge | BW-00-0008 | 1 | -- | -- |
| TurboCentras | Bearing housing | BW-01-0059 | 1 | -- | -- |
| TurboCentras | Shaft and wheel | BW-02-0005 | 1 | 5303-120-5039, 5303-120-8507 | -- |
| TurboCentras | Compressor wheel | BW-03-0008 | 1 | -- | -- |
| TurboCentras | Compressor wheel | BW-03-0017 | 1 | -- | -- |
| TurboCentras | Repair kit | BW-04-0003 | 1 | -- | -- |
| TurboCentras | Heat shield | BW-05-0002 | 1 | -- | -- |
| TurboCentras | Nozzle ring assy. | BW-06-0009 | 1 | 5303-160-5023 | -- |
| TurboCentras | Back plate | BW-08-0024 | 1 | -- | -- |
| TurboCentras | Actuator | BW-10-0041 | 1 | -- | -- |
| TurboCentras | Shaft nut | BW-21-0004 | 1 | -- | -- |
| EE Turbo | Cartridge | K03-039B | 1 | -- | -- |
| TurboCentras | Thrust bearing | K03/04-120 | 1 | -- | -- |
| TurboCentras | Thrust flinger | K03/04-130 | 1 | -- | -- |
| TurboCentras | Retaining ring | K03/04-143 | 1 | -- | -- |
| TurboCentras | Retaining ring | K03/04-144 | 1 | -- | -- |
| TurboCentras | Retaining ring | K03/04-145 | 1 | -- | -- |
| TurboCentras | Oil deflector | K03/04-146 | 1 | -- | -- |
| TurboCentras | Thrust washer | K03/04-155 | 1 | -- | -- |
| TurboCentras | Piston ring | K03/04-160 | 1 | -- | -- |
| TurboCentras | Piston ring | K03/04-170 | 1 | -- | -- |
| TurboCentras | Gasket oil outlet | T-1 | 1 | -- | -- |
| TurboCentras | Gasket kit | TC-62-0021 | 1 | -- | -- |
| TurboCentras | Gasket kit | TC1043 | 1 | -- | -- |
53039700132, 03L253019A, 03L253019T, 5303 970 0132
Data updated: 2025-09-23 16:09:54
