Garrett
Turbo 724930-0008-R
Turbo 724930-0008-R
Couldn't load pickup availability
724930-0008 (03G253014H) - Turbocharger GTA1749MV
Brand: Garrett
Model: GT17 - GTA1749MV
Garrett Reference: 724930-0008
OEM Numbers: 03G253014H
724930-0008 - Alternative numbers
GHT (Garrett turbo number): 724930-0008
GHT (Garrett turbo number): 724930-5008S
724930-0008 - Turbo replacements
Replaced by: Garrett GTA1749MV 724930-0009, 03G253010J, 724930-5009S
Replaced by: Garrett GTA1749MV 724930-0010, 03G253010J, 724930-5010S
Replaced by: Garrett GTA1749MV 724930-0012, 03G253010J, 03G253014H, 03G253019A, 03G253019AV550, 724930-5012S
Replaced by: Garrett GTA1749MV 724930-5012S, 03G253014H
Replacement for: Garrett GT1749MV 724930-0001
Replacement for: Garrett GTA1749MV 724930-0002, 03G253019A, 724930-5002S
Replacement for: Garrett GT1749MV 724930-0003
Replacement for: Garrett GTA1749MV 724930-0004, 03G253019A, 724930-5004S
Replacement for: Garrett GTA1749MV 724930-0006, 03G253019AV550, 724930-5006S
724930-0008 - Turbo interchangeability
Interchangeable with: BMTS BM 40006262, 03G253010J, 03G253014H, 03G253019A, 03G253019AV550, 401TN100171
Interchangeable with: BorgWarner BV43-1874KXB419.18KVAXC 53039887005, 03G253010J, 03G253014H, 03G253019A, 5303 988 7005
Interchangeable with: BorgWarner GT1749V 57439900013, 03G253010J, 03G253014H, 03G253019A, 5743 990 0013
Interchangeable with: Garrett GT1749MV 724930-0001
Interchangeable with: Garrett GTA1749MV 724930-0002, 03G253019A, 724930-5002S
Interchangeable with: Garrett GT1749MV 724930-0003
Interchangeable with: Garrett GTA1749MV 724930-0004, 03G253019A, 724930-5004S
Interchangeable with: Garrett GTA1749MV 724930-0006, 03G253019AV550, 724930-5006S
Interchangeable with: Garrett GTA1749MV 724930-0009, 03G253010J, 724930-5009S
Interchangeable with: Garrett GTA1749MV 724930-0010, 03G253010J, 724930-5010S
Interchangeable with: Garrett GTA1749MV 724930-0012, 03G253010J, 03G253014H, 03G253019A, 03G253019AV550, 724930-5012S
Interchangeable with: Garrett GTA1749MV 724930-5012S, 03G253014H
Interchangeable with: EE Turbo GT1749MV Turbo-G016S, 03G253010J, 03G253014H, 03G253019AV550, 724930-0002, 724930-0004, 724930-0006, 724930-0008, 724930-0009, 724930-0010
| PART BRAND | PART NAME | PART REFERENCE | QTY | PART OE NUMBER | GARRETT PART NUMBER |
|---|---|---|---|---|---|
| TurboCentras | Bolt | BO-98-0004 | 1 | -- | -- |
| TurboCentras | Bolt | BO-98-0005 | 1 | -- | -- |
| TurboCentras | Cartridge | GA-00-0059 | 1 | -- | -- |
| TurboCentras | Bearing housing | GA-01-0090 | 1 | 703882-0002, 722282-0013, 722282-0062 | -- |
| TurboCentras | Shaft and wheel | GA-02-0068 | 1 | 433257-0010, 434533-0007, 434533-0009, 434533-0015, 434533-0035, 434533-0037, 434533-0058, 434533-0059 | -- |
| TurboCentras | Compressor wheel | GA-03-0029 | 1 | 702489-0002, 702489-0006, 702489-0009 | -- |
| TurboCentras | Repair kit | GA-04-0015 | 1 | -- | -- |
| TurboCentras | Heat shield | GA-05-0013 | 1 | -- | -- |
| TurboCentras | Nozzle ring assy. | GA-06-0022 | 1 | -- | -- |
| TurboCentras | Back plate | GA-08-0005 | 1 | 700593-0006 | -- |
| TurboCentras | Turbine housing | GA-09-0009 | 1 | -- | -- |
| TurboCentras | Actuator | GA-10-0025 | 1 | -- | -- |
| TurboCentras | Compressor housing | GA-11-0003 | 1 | -- | -- |
| TurboCentras | Shaft nut | GA-21-0005 | 1 | -- | -- |
| TurboCentras | Actuator clip | GR.5 | 1 | -- | -- |
| EE Turbo | Cartridge | GT15-035 | 1 | -- | -- |
| TurboCentras | Thrust bearing | GT15-120 | 1 | -- | -- |
| TurboCentras | Thrust flinger | GT15-130 | 1 | -- | -- |
| TurboCentras | Thrust Collar | GT15-135 | 1 | -- | -- |
| TurboCentras | Retaining ring | GT15-143 | 1 | -- | -- |
| TurboCentras | Piston ring | GT15-160 | 1 | -- | -- |
| TurboCentras | Piston ring | GT15-170 | 1 | -- | -- |
| TurboCentras | Anti-rotation pin | GT15-330 | 1 | -- | -- |
| TurboCentras | VNT Ring | GT17-90-1 | 1 | -- | -- |
| TurboCentras | Screw | SC-96-0007 | 1 | -- | -- |
| TurboCentras | Gasket oil outlet | T-1 | 1 | -- | -- |
| TurboCentras | Gasket kit | TC1017 | 1 | -- | -- |
| TurboCentras | Washer | WA-95-0001 | 1 | -- | -- |
03G253014H, 724930-0008, 724930-5008S
Data updated: 2025-06-18 12:32:11
