IHI
Turbo VB17-R
Turbo VB17-R
Regular price
€231,40 EUR
Regular price
Sale price
€231,40 EUR
Unit price
/
per
Couldn't load pickup availability
VB17 (17201-26020, 17201-26021) - Turbocharger RHF4
Brand: IHI
Model: RHF4 - RHF4
IHI Reference: VB17
OEM Numbers: 17201-26020, 17201-26021
VB17 - Alternative numbers
IHT (IHI turbo number): VB17
| PART BRAND | PART NAME | PART REFERENCE | QTY | PART OE NUMBER | IHI PART NUMBER |
|---|---|---|---|---|---|
| TurboCentras | Cartridge | IH-00-0014 | 1 | -- | -- |
| TurboCentras | Bearing housing | IH-01-0018 | 1 | -- | -- |
| TurboCentras | Shaft and wheel | IH-02-0020 | 1 | -- | -- |
| TurboCentras | Compressor wheel | IH-03-0011 | 1 | -- | -- |
| TurboCentras | Repair kit | IH-04-0008 | 1 | -- | -- |
| TurboCentras | Heat shield | IH-05-0011 | 1 | -- | -- |
| TurboCentras | Nozzle ring assy. | IH-06-0007 | 1 | -- | -- |
| TurboCentras | Back plate | IH-08-0006 | 1 | -- | -- |
| TurboCentras | Shaft nut | IH-21-0002 | 1 | -- | -- |
| TurboCentras | Journal bearing | RHF4-100 | 2 | -- | -- |
| TurboCentras | Thrust bearing | RHF4-120 | 1 | -- | -- |
| TurboCentras | Thrust bearing | RHF4-121 | 1 | -- | -- |
| TurboCentras | Thrust flinger | RHF4-130 | 1 | -- | -- |
| TurboCentras | Retaining ring | RHF4-145 | 1 | -- | -- |
| TurboCentras | Thrust washer | RHF4-146 | 1 | -- | -- |
| TurboCentras | Bearing spacer | RHF4-149 | 1 | -- | -- |
| TurboCentras | Piston ring | RHF4-160 | 1 | -- | -- |
| TurboCentras | Piston ring | RHF4-170 | 1 | -- | -- |
| TurboCentras | Screw | SC-96-0002 | 3 | -- | -- |
| TurboCentras | Screw | SC-96-0006 | 4 | -- | -- |
| TurboCentras | Gasket oil outlet | T-1 | 1 | -- | -- |
| TurboCentras | Gasket kit | TC1038 | 1 | -- | -- |
17201-26020, 17201-26021, VB17
Data updated: 2024-10-22 10:03:07
